DETLOFF Compound plates
DETLOFF Compound plates are compound elements for a long service life under conditions of extreme wear and even at
elevated temperatures.
Application Example: linings of mills, ventilators, conveying screws, sliding guides, mixing troughs, concrete pumps,
screening machine coatings
Compound plates to prevent abrasive wear consist of semi-finished products or of metallic supports, on which
wear-protection layers,1.0 to 20.0 mm thick are connected metallically.
wear-protection-layers:
Nickle-based hard alloys with unique hard materials•HV0.3 hardness = 650 to 800
Nickel-based hard alloys with embedded chromium carbides and special hard materials•HV0.3 hardness = 1200 to 1400
Nickel-based hard alloys with embedded tungsten carbides•HV0.3 hardness = 1400 to 2000
Iron-based hard alloys with embedded chromium carbides and special carbides HRc 55-70 hardness (depending on the
composition of the alloy and the thickness of the layer.
HV 0.3 = Vickers hardness
HRc = Rockwell hardness
Compound plates consist of
Supporting material: |
|
Structural steel, boiler plate, stainless steel
Special materials on request |
Coating: |
|
All qualities from layers with a thickness from 1.0 mm upward (nickel basis), from 2 mm (based on iron) |
Plate size: |
|
Nickel-based hard alloys 600 x 800 mm
Iron-based hard alloys depending on the thickness:
600 X 800 mm
800 X 1850 mm to 1850 X 2850 mm, special sizes can be delivered upon request |
Blanks: |
|
plasma or water-jet cutting |
